Heat recovery
The waste heat in your cooling circuit is energy you have already paid for. With heat recovery from ONI you use it to heat production halls, storage areas and offices, instead of paying to blow that heat into the open air.
Heat recovery at Plastima
In almost every plastics processing plant waste heat is available in abundance: from the oil cooling of hydraulic units, from compressed air generation, from cooling water and from thermal processes. That heat is usually discharged to the outside air — and that costs money, because removing it takes energy too.
With the system technology of ONI you use energy you have already paid for not once, but two or three times. Plastima designs and supplies these installations and connects them to your existing cooling system.
Low-temperature heating modules
 |
At the heart of the technology are heat exchangers developed by ONI that work with a heating water temperature of only 35 °C. In injection moulding that is exactly the temperature coming out of the hydraulic cooling circuit: around 30 °C flow, around 35 °C return. Despite that low temperature the modules heat production and storage halls or offices with an even temperature distribution. Integration into existing underfloor heating is also possible. Technical features:
|
What it delivers
 |
For plastics processors, heat recovery is rarely a marginal saving. We have realised energy concepts in which no boiler installation was needed at all: 90% or more of the heat demand comes from machine and process heat, and only when there is no waste heat does an electric element step in. That saves not only fuel but also the investment in boilers, burners and flue systems — plus the floor area a boiler house takes up. There is a double effect on top of that: the heat you use no longer has to be cooled away. The electricity driving the hydraulics is thus put to good use three times over. Overview
|
ONI energy efficiency brochure
Contact details
Prefer to speak to someone? Call or email us.
Phone+31 76 571 43 02
Emailinfo@plastima.nl
AddressMinervum 7101, 4817 ZN Breda, the Netherlands
Get in touch about heat recovery
We respond within one working day.
